NGC 6302: The “Butterfly Nebula”

Hubble was recently retrained on NGC 6302, known as the "Butterfly Nebula," to observe it across a more complete spectrum of light, from near-ultraviolet to near-infrared, helping researchers better understand the mechanics at work in its technicolor "wings" of gas. The observations highlight a new pattern of near-infrared emission from singly ionized iron, which traces an S shape from lower left to upper right. This iron emission likely traces the central star system’s most recent ejections of gas, which are moving at much faster speeds than the previously expelled mass.

The star or stars at its center are responsible for the nebula's appearance. In their death throes, they have cast off layers of gas periodically over the past couple thousand years. The "wings" of NGC 6302 are regions of gas heated to more than 36,000 degrees Fahrenheit that are tearing across space at more than 600,000 miles an hour.

NGC 6302 lies between 2,500 and 3,800 light-years away in the constellation Scorpius.

About the colours

These images are a composite of separate exposures acquired by the WFC3/UVIS and WFC3/IR instruments on the Hubble Space Telescope. Several filters were used to sample narrow wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are: Purple: F502N Luminosity: F656N Green: F658N Cyan: F110W Orange: F164N

About the data

The HST observations include those from programs 15953 (J. Kastner)
