Multiwavelength OPAL Jupiter

Two views of Jupiter showcase the wealth of information provided by the spectral filters on the Hubble Space Telescope's Wide Field Camera 3 (WFC3) science instrument. At left, the RGB composite is created using three filters at wavelengths similar to the colors seen by the human eye. At right, the wavelength bounds are widened beyond the visible range to extend just into the ultraviolet (UV) and infrared regimes. Humans cannot perceive these extended wavelengths, but some animals (such as mantis shrimp, whose eyes function similarly to certain sensors on some NASA missions) are able to detect infrared and ultraviolet light. The result is a vivid disk that shows UV-absorbing lofty hazes as orange (over the poles and in three large storms, including the Great Red Spot), and freshly-formed ice as white (compact storm plumes just north of the equator). Astronomers, including the OPAL team, use these filters (and others not shown here) to study differences in cloud thickness, altitude, and chemical makeup.

About the colours

These images are a composite of separate exposures acquired by the WFC3 instrument on the Hubble Space Telescope. Several filters were used to sample medium wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are: Blue: F395N & F343N, Green: F502N & F467M, Red: F658N & FQ889N

About the data

The HST observations include those from the OPAL observing programs (A. Simon)
