Jupiter Map

False color cylindrical map of Jupiter, constructed from a set of images of the planet obtained with the WFPC2 on the Hubble Space Telescope. Individual frames were obtained on May 9 and May 10, 2008. The images were deprojected and mosaiced together. The map shows latitudes between +/-70 deg. The resolution is a quarter degree in latitude and longitude. Images were combined at 673, 502, and 410 nm, as red, green, and blue colors.

About the colours

These images are a composite of separate exposures made by the WFPC2 instrument on the Hubble Space Telescope. Three filters were used to sample various wavelength ranges. The color results from assigning different hues (colors) to each monochromatic image. In this case, the assigned colors are: Blue: F410 M Green: F502 N Red: F673 N

About the data

HST Proposal: 11102 I. de Pater, P. Marcus, M. Wong, and X. Asay-Davis (University of California, Berkeley), and C. Go (University of San Carlos, Philippines).
